1SS306
立即咨询PDF下载
1SS306
Switching diode
Description
| Feature | High breakdown voltage |
|---|---|
| Internal Connection | Independent |
| Number of Circuits | 2 |
| Assembly bases | Japan |
| RoHS Compatible Product(s) (#) | Available |
Package Information
| Toshiba Package Name | SMQ |
|---|---|
| Package Image |
|
| JEITA | SC-61 |
| Package Code | SOT-24 |
| Pins | 4 |
| Mounting | Surface Mount |
|
Width×Length×Height (mm) |
2.9×2.9×1.1 |
| Package Dimensions | View |
| Land pattern dimensions | View |
Please refer to the link destination to check the detailed size.
Absolute Maximum Ratings
| Characteristics | Symbol | Rating | Unit |
|---|---|---|---|
| Average Forward Current | IO | 0.1 | A |
| Reverse Voltage | VR | 200 | V |
