CMS15
立即咨询PDF下载
CMS15
Schottky barrier diode
产品概要
| Application Scope | Switching-mode power supplies / Mobile equipment batteries |
|---|---|
| Internal Connection | Single |
| RoHS Compatible Product(s) (#) | Available |
| Assembly bases | 日本 / 马来西亚 |
封装类型
| Toshiba Package Name | M-FLAT |
|---|---|
| Package Image |
|
| Pins | 2 |
| Mounting | Surface Mount |
|
Width×Length×Height (mm) |
2.4×4.7×0.98 |
| Package Dimensions | 查看 |
| Land pattern dimensions | 查看 |
Please refer to the link destination to check the detailed size.
Absolute Maximum Ratings
| Characteristics | Symbol | Rating | Unit |
|---|---|---|---|
| Average Forward Current (Single) | IF(AV) | 3 | A |
| Repetitive Peak Reverse Voltage | VRRM | 60 | V |
产品特性
| 项目 | 符号 | 条件 | 数值 | 单位 |
|---|---|---|---|---|
| Peak Forward Voltage (Max) | VFM | - | 0.58 | V |
| Repetitive Peak Reverse Current | IRRM(MAX) | VRRM=60V | 0.3 | mA |
