1SS416
立即咨询PDF下载
1SS416
Small-signal Schottky barrier diode
产品概要
| Feature | High-speed switching / Low VF |
|---|---|
| Internal Connection | Single |
| Number of Circuits | 1 |
| RoHS Compatible Product(s) (#) | Available |
| Assembly bases | 日本 / 泰国 |
封装类型
| Toshiba Package Name | SOD-923 |
|---|---|
| Package Image |
|
| Package Code | SOD-923 |
| Pins | 2 |
| Mounting | Surface Mount |
|
Width×Length×Height (mm) |
1.0×0.6×0.4 |
| Package Dimensions | 查看 |
| Land pattern dimensions | 查看 |
Please refer to the link destination to check the detailed size.
Absolute Maximum Ratings
| Characteristics | Symbol | Rating | Unit |
|---|---|---|---|
| Average Forward Current | IO | 0.1 | A |
| Reverse Voltage | VR | 30 | V |
产品特性
| 项目 | 符号 | 条件 | 数值 | 单位 |
|---|---|---|---|---|
| Forward Voltage (Max) | VF | IF=100mA | 0.50 | V |
| Forward Voltage (Typ.) | VF | IF=1mA | 0.18 | V |
| Forward Voltage (Typ.) | VF | IF=5mA | 0.23 | V |
| Forward Voltage (Typ.) | VF | IF=100mA | 0.38 | V |
| Reverse Current | IR | VR=30V | 0.05 | mA |
